Hydraulic Hot Molding Press for Brake Lining/Brake Pad/Clutch Plates

Our Hydraulic Hot Molding Presses are fabricated for hot molding of carbon powder for brake lining, pallets, brake shoes, disk pads, briquettes, etc. These presses are rigid, compact and high in speed mainly designed for Brake Lining Industries. These Hydraulic Molding Press are simple and easy in installment and incorporates latest technology to provide effective operations.

Hydraulic Hot Molding Press for Brake Lining/Brake Pad/Clutch Plates

MODEL NO.	CAP. (TONs)	PLATEN SIZE (mm)	NO. OF DAY LIGHT	DAYLIGHT GAP (MM)	STROKE	BORE / RAM DIA	MOTOR (h.p)
FHM 150	150	500 X 500	2	300 EACH	400	300	7.5	Send Enquiry
FHM 200	200	600 X 600	2	350 EACH	500	350	10	Send Enquiry
FHM 250	250	700 X 700	2	400 EACH	600	400	10	Send Enquiry
FHM 300	300	800 X 800	2	400 EACH	600	450	15	Send Enquiry
FHM 400	400	900 X 900	2	400 EACH	600	510	20	Send Enquiry
FHM 500	500	1000 X 1000	2	450 EACH	600	560	20	Send Enquiry
FHM 600	600	1200 X 1200	2	450 EACH	600	610	25	Send Enquiry
FHM 800	800	1200 X 800	2	750 EACH	500	710	30	Send Enquiry
FHM 1000	1000	1200 X 1200	2	900 EACH	550	810	35	Send Enquiry

Note:
» The Press can be designed be available with Pillar / Gate / H-Frame Type
» The Press can have multiday lights (1,2,3,4)
» The press can be multi station(1,2,3,4)
» For multistation press, motor h.p. will change accordingly
» Click here to Request a Quotation for Hydraulic Press over & above the specified capacity.
